Product Characteristics

Function & Purpose:
The 250 x 250 mm raised floor box is a compact, recessed electrical outlet enclosure designed for raised access flooring systems. It provides easy and organized access to power, data, and communication outlets within office, conference, and commercial environments.

Dimensions & Structure:

Overall Size: 250 mm x 250 mm (nominal)

Depth: Typically 70–100 mm, depending on module configuration

Mounting Type: Recessed into raised access floor panels

Load Bearing: Designed to support normal foot traffic and office furniture loads

Construction & Materials:

• Housing / Box: Galvanized steel or powder-coated mild steel for corrosion resistance and strength.
• Cover / Lid:
• • Flush-fitting with floor level
  • Anti-slip finish
  • Option for floor finish insert (e.g., carpet, vinyl, tile) for aesthetic continuity

Internal Modules: Modular Compartments for

• Power sockets (2nos.)
• Data / RJ45 ports
• Plain plates (optional)

Electrical & Data Specifications:

• Rated Voltage: 220–240V AC (50/60Hz)
• Current Rating: 10–16A per socket
• Wiring Entry: Through knockouts for conduits or flexible cables beneath raised floors
• Grounding: Integrated earthing terminal for electrical safety


 Recommendations and Restrictions

 Recommendations

• Ensure installation on stable raised floor panels with sufficient underfloor clearance for wiring.
• Use certified and compatible modules
• Periodically inspect for loose connections, worn contacts, or damaged covers.
• Plan cable routes and conduit positions before installation to ensure ease of maintenance.

Restrictions

·        Do not exceed the rated current (16A) or connect high-load equipment directly.

·        Avoid installation in wet or outdoor environments unless the floor box has an IP-rated cover.

·        Do not install non-raised floor systems without proper adaptation or recess depth.

·        Avoid placing heavy or rolling loads directly on the lid if not designed for such use.

·        Do not modify or drill through the housing — use provided knockouts only.

·        Not suitable for hazardous or explosive environments without certified protection.
